Pan head screw M06x12

SKU 21.2074/0 Category

Assembly of surface elements directly on profile groove

£1.19 + VAT

Pan head screw M06x12
Pan head screw M06x12 - Image 2
Pan head screw M06x12 - Image 3

Technical Data

  • Steel, galvanized
  • Thread (d) : M 6
  • Length (l) : 12 mm
  • Head diameter Ø 20 mm
  • Weight = 0.009 kg/piece

Applications

  • Assembly of surface elements directly on profile groove
  • In connection with screw blocks, multiblocks and thread socket

Assembly

  • Pre-drill surface elements:  Ø 6.5 mm
  • Recommended grid dimensions: approx. 150 mm
  • Edge distance: see screw block 32 and multi-block
